主要尺寸與性能資料
| d | 5.9375 in | Shaft diameter |
| H | 18 in | 軸承座 height |
| B | 25 in | Length base |
| ≈m | 373.998 lbs | 重量 |
尺寸
S2BCH-515-FL | Complete unit float | |
S2BCH-515-HD | Complete unit held | |
PH-21 | 軸承座 designation | |
| A | 10.25 in | Center height |
| C | 8 in | Base width |
| D | 2 in | Base height |
| Emin | 21.5 in | Base hole distance 1 min |
| Emin | 22.5 in | Base hole distance 1 max |
| F | 5 in | Base hole distance 2 |
| s | 4 | # of mounting bolts |
| s | 1 in | Mounting bolt diameter |
S2BC-515-FL | Cartridge float bearing | |
S2BC-515-HD | Cartridge held bearing | |
S2C-600 | Cartridge | |
| G | 7.9375 in | Length through bore |
| L | 13.25 in | 外徑 cartridge |
3 lbs | Grease capacity | |
162 lbs | Cartridge weight | |
S2B-515-FL | Bearing float | |
S2B-515-HD | Bearing held | |
70.4 lbs | Bearing weight | |
600 Grp | Bearing group | |
| Cr | 147,326 lbf | 基本額定動載荷，徑向 |
| C0r | 229,303 lbf | 基本額定靜態負荷，徑向 |
| Ca | 1,138 lbf | 基本額定動載荷，軸向 |
1,450 1/min | 極限轉速 | |
| D0 | 11.5 in | 外徑 bearing |
| C0 | 4.875 in | 內圈寬度 |
| B0 | 2.668 in | Width outer ring |
