FAG INA Schaeffler
FAG
S2B-900-FL
Plummer block housing unit S2B-900-FL
加入詢價
主要尺寸與性能資料
d
228.6 mm
Shaft diameter
≈m
67.132 kg
重量

尺寸
S2B-900-FL
Bearing float
S2B-900-HD
Bearing held
Ca
58,050.848 N
基本額定動載荷，軸向
Cr
964,490.976 N
基本額定動載荷，徑向
C0r
1,653,263.776 N
基本額定靜態負荷，徑向
1,091 1/min
極限轉速
D0
393.7 mm
外徑 bearing
C0
162.611 mm
內圈寬度
B0
90.5 mm
Width outer ring
