ARCALUB-X.PINION-MD10,0-Z17-B100-SL-W
Lubrication gear ARCALUB-X.PINION-MD10,0-Z17-B100-SL-W
加入詢價
科技數據
Relubrication of tooth sets
Usage
left hand helical teeth
Design
radial
Lubricant feed
open cell PU foam
Material
top
-30 °C ... +140 °C
Operating temperature
5 m/s
Max. permissible circumferential speed at 外徑
Oil, greases up to NLGI 2
Lubricant
m
10 mm
Modulus
z
17
Teeth number
d
180.38 mm
Pitch circle diameter
da
200.4 mm
B
100 mm
L
131 mm
β
19.53 °
Helix angle
≈m
0.9 kg
重量

您目前的產品型號
VersionSLLubrication gears, left hand helical teeth
